Prodcut Number:
Delivering 6600LM of powerful brightness, our IP68/69K waterproof LED headlight is built with heavy-duty shock resistance and a 50,000-hour lifespan. Certified ISO9001, IATF16949, CE & RoHS, it’s engineered for automotive, marine, and industrial use.
John Deere:
AL178138 (RH)
AL178164 (LH)
Certified,reliable,andenergy-efficient,theMFLamps LED Headlight ensures superior visibility in the toughest conditions.
| Voltage | 12/24 V | Amperage | 7.5A |
| Consumption | 90W | Operational Lumen | 6600 Lumen |
| Color Temperature | 6000 K for crystal version | Light pattern | HIGH/LOW |
| Color | Crystal | Connector | / |
| Mounting | Pedestal | Fixation | To be screwed |
| Lens Material | Polycarbonate plastic cover | Housing Material | Aluminium |
| size(Width * Depth * Height) | 127mm * 79mm * 127mm | Weight | 0,55 Kg |
| IP protection | IP68 - IP69K | Polarity | Protected against reverse voltage |
| Electronic Thermal Management | Full output at +35°C ambiant, 25 % dimmed at + 50°C ambiant | Operation Temperatures | -40°C to +85°C |
| Load Dump | 36V CONTINUOUS / ISO 7637-2 Pulse 5a | Salt Spray Test | ISO 9227 |
| Vibration Resistance | 15 Grms, from 24Hz to 2000Hz | Shock resistance | 60G |
| Lifetime | 30 000 operating hours | EMC | ECE R10, CISPR25 CLASS 4 |
With over 10 years of experience in LED lighting for automotive and off-highway equipment, M&F provides customized, high-quality solutions. Our tailored designs and reliable performance drive client growth and success.
