Prodcut Number:
MFLamps LED signal lights deliver 1920LM brightness with IP68/69K waterproofing, heavy-duty shock resistance, and 50,000-hour lifespan—certified ISO9001, IATF16949, CE & RoHS for automotive, marine, and industrial applications
Replaces OEM Part Numbers: John Deere AL215077, AL181871
Fitment Information：Case/IH Combine: 1440, 1460, 1480, 1620, 1640, 1644, 1660, 1666, 1670, 1680, 1682, 1688, 2144, 2166, 2188, 2344, 2366, 2377, 2388, 2577, 2588 Case/IH Cotton Harvester:1800 Case/IH Cotton Picker: 420, 620, 782, 1400, 1822, 1844, 2022, 2044, 2055, 2155, 2555, CPX420, CPX610 Case/IH Tractor: 385, 395, 485, 495, 585, 685, 695, 885, 895, 995, 1086, 3220, 3230, 4210, 4230, 4240, 7110, 7120, 7130, 7140, 7150, 7210, 7220, 7230, 7240, 7250, 8910, 8920, 8930, 8940, 8950, CX100, CX50, CX60, CX70, CX80, CX90, MX100, MX100C, MX110, MX120, MX135, MX150, MX170, MX80C, MX90C Case/IH Windrower:4000, 5000 Ford New Holland Tractor: 9184, 9384, 9484, 9684, 9884, 9030E, 9030V International Combine:1400, 1420, 1470, 1482 International Tractor: 385, 484, 584, 784, 786, 886, 986, 1086, 1486, 1586, 3088, 3288, 3388, 3488, 3588, 3688, 3788, 4386, 4586, 4786, 5088, 5288, 5488, 6388, 6488, 6588, 6788 Versatile Tractor: 9280, 9282, 9480, 9482, 9680, 9682, 9880, 9882, 1156V, 256V, 276V, 276VII, 756V, 836V, 846V, 856V, 876V, 936V, 946V, 956V, 976V
Certified, energy-efficient, and highly durable—MFLamps LED signal lights are your ideal choice for clear, unmistakable visual signaling.
| Voltage | 10-30V | Amperage | 2A |
| Consumption | 24W | Operational Lumen | 1920Lumen |
| Color Temperature | 5700 K for crystal version | Light pattern | Combination Beam |
| Color | Crystal | Connector | / |
| Mounting | Pedestal | Fixation | To be screwed |
| Lens Material | Polycarbonate plastic cover | Housing Material | PC |
| size(Width * Depth * Height) | mm * mm * mm | Weight | 0,55 Kg |
| IP protection | IP68 - IP69K | Polarity | Protected against reverse voltage |
| Electronic Thermal Management | Full output at +35°C ambiant, 25 % dimmed at + 50°C ambiant | Operation Temperatures | -40°C to +80°C |
| Load Dump | 36V CONTINUOUS / ISO 7637-2 Pulse 5a | Salt Spray Test | ISO 9227 |
| Vibration Resistance | 15 Grms, from 24Hz to 2000Hz | Shock resistance | 60G |
| Lifetime | 50 000 operating hours | EMC | ISO 13766 - ISO 14982 - ISO 12985 - CISPR25 Class 5 |
With over 10 years of experience in LED lighting for automotive and off-highway equipment, M&F provides customized, high-quality solutions. Our tailored designs and reliable performance drive client growth and success.
